RxPS2AllPipeData Struct Reference
[PS2All]

Data Fields

A pointer to a pointer to a RwResEntry holding the instance data for the mesh

Internal Use

RwRGBA material color value. Initialised by default to {255, 255, 255, 255}

RwUInt8 specifying whether or not to modulate the object material colors (0 means FALSE)

A pointer to the private data of the current material pipeline's PS2AllMat node

A pointer to the source RpMesh

A pointer to the RwMeshCache associated with meshHeader

A pointer to the source object's RpMeshHeader

Per-mesh data that gets written into the PS2ResHeader such that state changes since creation of the instance data can be detected by object-specific code.

Optionally set by the MeshReInstanceTest CB, overrides objInstance in saying whether to instance the mesh and if so whether to do in-place, congruent or full reinstancing (and if in-place which clusters to reinstance)

Internal Use

Per-object, object-type-specific data that gets written into the PS2ResHeader such that state changes since creation of the instance data can be detected by object-specific code

Set by the ObjectSetup CB, says whether to instance the object and if so whether to do in-place, congruent or full reinstancing (and if in-place which clusters to reinstance)

A pointer to the private data of the currently executing PS2All (object-pipeline) node

RwUInt8 code for the primitive type that will be submitted by VU1 to the GS (see GS manual ~p113)

A pointer to the source object

An extra RwReal that can be uploaded in the same quadword as the surface properties. It is initialized by default to zero and persists between meshes.

A pointer to the current material surface properties. If left NULL, default {1, 1, 1} surface properties will be used.

A pointer to a RwTexture for the current mesh

RwUInt8 flags, specifying the type of transform to use (ortho/persp, fog/not, etc - see RxSkyTransTypeFlags)

RwUInt8 index into VU code array,
